Magnetic Bearing: Types, How It Works, and Key Applications

Author: Heyang Date: Jun 22, 2026

Content

What Is a Magnetic Bearing and Why Does It Matter

A magnetic bearing is a type of bearing that supports a rotating shaft entirely through magnetic force, with no physical contact between the rotor and the stator. Unlike conventional rolling-element bearings or fluid-film bearings, a magnetic bearing uses controlled electromagnetic fields to levitate the shaft in space — eliminating mechanical friction, wear, and the need for lubrication. The result is a bearing system capable of operating at extreme speeds, in vacuum environments, and at temperatures where conventional bearings would fail outright.

The practical significance of this is large. In industrial compressors, turbomachinery, energy storage flywheels, and semiconductor manufacturing equipment, the removal of contact-based wear translates directly into longer machine life, lower maintenance cost, and more precise rotational control. A magnetic bearing does not simply replace a rolling bearing — it changes the performance envelope of whatever machine it is installed in.

1,000,000+ RPM achievable with active magnetic bearings in lab conditions
0 Lubrication required — no oil, no grease, no contamination
<1 µm Rotor position accuracy in precision active magnetic bearing systems

Types of Magnetic Bearings: Active, Passive, and Hybrid

Magnetic bearing technology divides into three broad families, each with a distinct operating principle. Understanding the differences determines which bearing configuration is appropriate for a given application.

AMB

Active Magnetic Bearing (AMB)

An active magnetic bearing uses electromagnets energized by a real-time feedback controller. Sensors continuously measure rotor position; the control system adjusts current in each electromagnet to keep the shaft centered. This makes AMBs inherently unstable without control — but the control loop also gives the system programmable stiffness, active vibration damping, and diagnostic capability. AMBs are the dominant form in industrial turbomachinery, including natural gas pipeline compressors and high-speed spindles.

PMB

Passive Magnetic Bearing (PMB)

A passive magnetic bearing uses permanent magnets to generate a static repulsive or attractive force without any power supply or control electronics. By Earnshaw's theorem, a purely passive magnetic bearing cannot be stable in all six degrees of freedom simultaneously — so PMBs are typically combined with mechanical elements to constrain unstable axes. They are used in energy storage flywheels as radial support bearings, with an AMB or pivot handling the remaining axes.

HMB

Hybrid Magnetic Bearing

A hybrid magnetic bearing combines permanent magnets with small electromagnets. The permanent magnet provides the baseline levitation force — called the bias flux — while the electromagnet provides a smaller, faster-responding trim current. Because the permanent magnet carries most of the load, the power drawn by the control coil is significantly lower than a fully active bearing. This makes hybrid bearings well suited to battery-backed systems and applications where power consumption is tightly constrained.

How an Active Magnetic Bearing Works: The Control Loop Explained

Understanding active magnetic bearing operation means following the signal path from sensor to actuator. The process repeats thousands of times per second.

01

Position Sensing

Eddy-current or inductive sensors measure the air gap between the rotor and each bearing electromagnet. Sensing resolution is typically in the micron range. Most industrial AMB systems use redundant sensors to ensure that a single sensor failure does not cause a rotor drop.

02

Signal Processing and Control Algorithm

The measured gap signal is compared with a setpoint. The error drives a PID or more advanced control algorithm — some systems use H-infinity or model predictive control — that computes the required correction force. The controller runs on dedicated DSP or FPGA hardware at update rates of 10 kHz to 50 kHz or higher.

03

Power Amplifier and Electromagnet

The controller output drives a linear or switching power amplifier, which adjusts the current flowing through each bearing electromagnet. The resulting magnetic force acts on the ferromagnetic rotor, correcting its position. An axial AMB uses a thrust disk to control position along the shaft axis.

04

Auxiliary (Backup) Bearings

Every AMB system includes touchdown or auxiliary bearings — typically rolling-element bearings with a small clearance relative to the magnetic bearing. In normal operation they carry no load. On power loss or control fault, they catch the rotor and prevent destructive contact with the electromagnet poles. Touchdown bearings must be designed to absorb a specified number of drop events without failure, as defined in standards such as ISO 14839.

Advantages of Magnetic Bearings Over Conventional Bearings

The performance gap between magnetic bearing technology and conventional rolling-element or fluid-film bearings is significant. The following table compares key parameters across bearing types for high-speed industrial applications.

Comparison of bearing technologies for high-speed rotating machinery. Data compiled from SKF bearing engineering guides and Waukesha Bearings AMB application literature.
Parameter Rolling-Element Bearing Fluid-Film Bearing Active Magnetic Bearing
Max peripheral speed ~150 m/s ~200 m/s >600 m/s
Friction losses Moderate High at low speed Near zero
Lubrication required Yes (grease or oil) Yes (pressurized oil) No
Vibration monitoring External sensors needed External sensors needed Integrated (AMB sensors)
Operating temperature range Up to ~180°C (grease) Up to ~150°C (oil) Up to 450°C+ (coil dependent)
Wear over time Continuous Start/stop wear Zero (rotor never contacts stator)
Control / programmability None Limited Full (stiffness, damping, imbalance rejection)

The elimination of lubrication is particularly significant for process industries. In natural gas compression, oil contamination of the process gas is a continuous operational concern with conventional bearing systems. A magnetic bearing removes this risk entirely, simplifying the seal system and reducing operational cost. According to data published by SKF Magnetic Mechatronics, upgrading a centrifugal compressor from oil-lubricated bearings to AMBs can eliminate the lube oil skid, the oil separator, and the associated filtration systems — saving several hundred thousand dollars in capital cost on large-frame machines.

Where Magnetic Bearings Are Used: Key Industrial Applications

Magnetic bearing systems are not a niche technology. They are deployed in high-stakes rotating equipment across a wide range of industries, wherever the combination of high speed, contamination sensitivity, or maintenance minimization outweighs the higher initial system cost.

Energy

Gas Compression and Pipeline

Large centrifugal compressors in natural gas pipeline stations have been one of the primary industrial adopters of active magnetic bearing technology. Manufacturers including Siemens Energy, Baker Hughes, and MAN Energy Solutions offer compressors with integrated AMBs as a standard or optional configuration. The oil-free operation is critical in facilities where open flame or spark risk makes oil handling hazardous, and in remote unmanned installations where eliminating lube oil maintenance is a direct operational cost reduction.

Manufacturing

High-Speed Machine Tool Spindles

Precision machining of aerospace components requires spindle speeds that exceed what conventional rolling-element bearings can sustain without rapid degradation. Magnetic bearing spindles can operate at 60,000 RPM and above, and the active control system allows the spindle to actively compensate for tool imbalance, extending tool life and improving surface finish. Research published in the International Journal of Machine Tools and Manufacture has shown that AMB spindles reduce chatter-induced surface error compared to conventional spindle systems at equivalent cutting depths.

Energy Storage

Flywheel Energy Storage Systems

A flywheel energy storage system stores kinetic energy in a spinning mass. The efficiency of such a system depends critically on minimizing bearing losses, because the rotor may spin at high speed for hours or days between charge and discharge cycles. Combining passive permanent magnet bearings for radial support with a small AMB for axial control — and housing the rotor in vacuum — brings windage and bearing losses to a level where flywheels become competitive with electrochemical batteries for short-duration grid storage applications. Beacon Power's flywheel plants in Stephenville, Texas and Hazle Township, Pennsylvania use this bearing configuration, providing frequency regulation services to the grid.

Semiconductor

Vacuum Turbo-Molecular Pumps

Turbo-molecular pumps used in semiconductor fab equipment must operate in high vacuum, at speeds above 50,000 RPM, without any lubricant contamination of the process chamber. Magnetic bearings — typically hybrid permanent magnet plus small trim electromagnets — are standard in the majority of turbo-molecular pumps produced by Pfeiffer Vacuum, Edwards, Leybold, and similar manufacturers. The rotor levitates and spins without any contact, keeping the vacuum environment uncontaminated.

Medical

Ventricular Assist Devices

Left ventricular assist devices (LVADs) — implanted pumps that support or replace the function of a failing heart — have moved from axial-flow designs with conventional bearings to centrifugal designs where the impeller is magnetically levitated. The HeartMate 3, approved by the FDA and used widely in clinical practice, uses full magnetic levitation of the rotor with no mechanical contact points. The elimination of bearing contact surfaces removes the primary site of thrombus formation in earlier devices, contributing to significantly improved clinical outcomes compared to prior-generation pumps, as documented in the MOMENTUM 3 clinical trial published in the New England Journal of Medicine.

HVAC

Magnetic Bearing Chillers

Centrifugal chillers for commercial building HVAC have adopted magnetic bearing technology in the compressor stage. Daikin, Johnson Controls (York brand), and Danfoss (Turbocor) all market chiller compressors where the compressor shaft rides on AMBs. The efficiency gain comes from two directions: elimination of mechanical bearing friction, and the ability to run the compressor at variable speed without a gearbox, allowing the unit to match partial-load conditions precisely. Turbocor compressors claim part-load efficiency improvements of 35% or more over traditional oil-lubricated centrifugal compressors under AHRI rating conditions.

Rotor Design Considerations for Magnetic Bearing Systems

The rotor in a magnetic bearing system must be designed to work with the electromagnetic circuit, not independently of it. This requires a different engineering approach than rotors designed for rolling-element or hydrodynamic bearings.

Material Selection: Laminated vs. Solid Steel

The rotor material at the bearing landing zone must be ferromagnetic — the magnetic force acts on the iron in the rotor. However, a solid ferromagnetic rotor exposed to the alternating magnetic field of an AMB generates eddy current losses that heat the rotor and reduce bearing actuator efficiency. For this reason, AMB rotors often use laminated silicon steel at the bearing journals, similar to the lamination stacks used in electric motor cores, to break up the eddy current paths. In high-temperature applications where silicon steel laminations degrade, solid material with an optimized pole geometry is used and the eddy current losses are managed through control frequency selection.

Balancing Requirements

Because an AMB can actively compensate for synchronous vibration, it is sometimes assumed that rotor balance requirements are relaxed. In practice, the opposite is true. The AMB control system must apply continuously varying forces to suppress imbalance response — forces that generate heat in the electromagnets and consume amplifier current. A poorly balanced rotor shortens the thermal margin of the bearing system and reduces available force for disturbance rejection. ISO 1940 G1 or better balancing quality is typically specified for AMB rotors, and some applications require active imbalance identification and compensation through the AMB control system itself.

Critical Speed Mapping and Separation Margins

All rotating shafts have bending critical speeds — rotor speeds at which a bending mode is excited and amplified by resonance. In a conventional bearing, the stiffness and damping of the bearing are fixed by the geometry and lubricant properties. In an AMB, the stiffness and damping are tunable through the control algorithm. This means that an AMB rotor can be designed to pass through a bending critical speed under controlled conditions, with the controller applying damping to suppress the response. This is a significant design freedom — it allows longer, more slender rotors than would be practical with fixed-stiffness bearings. The rotor analyst and the control engineer must work together from the early design phase to map the critical speed landscape and design the control response accordingly.

Auxiliary Bearing Clearance and Drop Event Analysis

The clearance between the rotor and the auxiliary (touchdown) bearings is a critical design parameter. It must be small enough that the rotor does not build up destructive momentum before contacting the auxiliary bearing, but large enough that normal rotor thermal growth and imbalance orbits do not cause inadvertent contact. Typical AMB-to-rotor clearances run from 0.3 mm to 0.8 mm depending on rotor size, with the auxiliary bearing clearance set at roughly half the AMB clearance. Drop event simulations using transient rotor dynamics software are performed to verify that the auxiliary bearings and their support structure can survive the specified number of drop events without structural failure.

Magnetic Bearing Control Systems: From PID to Model-Based Approaches

The control system is what separates an active magnetic bearing from a simple electromagnet. The sophistication of the controller determines the achievable stiffness bandwidth, the quality of vibration rejection, and the diagnostic capability of the bearing system.

Classical PID Control

Proportional-integral-derivative control applied individually to each bearing axis is the baseline approach for most industrial AMB systems. Proportional gain provides stiffness, derivative gain provides damping, and integral gain eliminates steady-state position error. Cross-coupling between axes — the fact that a force in one direction can move the rotor in another — is typically handled by decoupling filters. PID control is well understood, easy to commission, and robust, making it the practical standard for the majority of installed industrial magnetic bearings.

Notch Filters and Synchronous Cancellation

A rotating unbalanced rotor generates a synchronous forcing at exactly 1x running speed. If the AMB control loop has gain at this frequency, it will try to control out the synchronous response — expending current to do so. A synchronous cancellation algorithm identifies the 1x component from the position signal and subtracts it from the control input, so the bearing "ignores" synchronous imbalance and lets the rotor rotate around its mass center. This reduces bearing currents at running speed and is standard in industrial AMB controllers. Notch filters at specific resonant frequencies further shape the stability margins.

H-Infinity and Robust Control

For machinery with complex rotor dynamics — multiple flexible modes, strong gyroscopic coupling at high speed, or tightly spaced critical speeds — classical PID may not provide adequate stability margins across the full operating speed range. H-infinity control synthesizes a controller that minimizes the worst-case gain from disturbance inputs to controlled outputs, subject to an explicit model of the plant uncertainty. This allows stable operation across a wider range of rotor conditions and is used in demanding applications such as high-speed machining spindles and aerospace turbo-machinery prototypes.

Self-Sensing and Sensorless Bearings

Standard AMBs require dedicated position sensors. Sensorless or self-sensing AMBs extract rotor position information from the variation in inductance of the bearing coils as the air gap changes, using high-frequency carrier signal injection or other estimation methods. Eliminating dedicated sensors reduces cost, improves reliability in harsh environments, and makes the bearing more compact. Research groups at ETH Zurich and other institutions have demonstrated self-sensing AMBs with performance approaching sensored systems, though commercial adoption remains limited to specific applications.

How to Select the Right Magnetic Bearing Configuration for Your Application

Selecting a magnetic bearing system requires matching the bearing type and configuration to the specific requirements of the application. The following criteria drive the selection decision.

  • Load capacity and direction: AMBs are well suited to radial and axial loads in rotating machinery. For very high static loads, the required electromagnet power can become large; a hybrid bearing using permanent magnets for the bias load reduces power consumption substantially.
  • Speed range: Magnetic bearings excel at high peripheral speeds. If the application speed is below 10,000 RPM and load capacity requirements are moderate, the cost premium of an AMB system may not be justified over a well-designed fluid-film or rolling-element bearing. Above 30,000 RPM, magnetic bearings are typically the superior option.
  • Environment: Vacuum, high temperature, cryogenic, or chemically aggressive environments favor magnetic bearings strongly because conventional lubrication systems are either impossible or extremely costly to implement. Turbo-molecular pumps and cryogenic expanders are clear cases.
  • Maintenance access: Remote or unmanned installations — offshore platforms, deep-sea equipment, pipeline compressor stations — benefit significantly from eliminating oil-lubricated bearings, because each lubrication service requires a site visit and carries significant cost and risk.
  • Contamination sensitivity: Any process where oil or grease contamination of the product or process fluid is unacceptable points to magnetic bearings. Semiconductor manufacturing, food processing, pharmaceutical, and oxygen compression are examples.
  • Diagnostic requirements: If continuous health monitoring of rotor dynamics is important for process integrity or predictive maintenance, the integrated sensors of an AMB system provide this as a by-product of normal operation, at no additional sensor cost.
  • Power supply reliability: Every AMB system requires continuous power to maintain levitation. Applications in environments where power supply reliability is uncertain must include an uninterruptible power supply (UPS) or energy storage device to provide controlled rundown power for the AMB and orderly drop to touchdown bearings.

Maintenance of Magnetic Bearing Systems: What to Expect in Practice

One of the strongest selling points of magnetic bearing technology is reduced maintenance burden. However, "reduced" is not "zero" — understanding what maintenance a magnetic bearing system actually requires is important for lifecycle cost planning.

What Magnetic Bearings Eliminate

  • Periodic lubricant analysis and change-out
  • Lube oil system inspection (filters, pumps, reservoir)
  • Bearing wear measurement and replacement based on fatigue life
  • Oil seal inspection and replacement
  • Grease nipple servicing

What Magnetic Bearings Require

  • Annual or bi-annual verification of control system calibration and sensor function
  • Periodic inspection and replacement of touchdown (auxiliary) bearings, typically every 3–5 years or after a specified number of drop events
  • Review of control system software and firmware for updates
  • UPS battery testing and replacement on the scheduled battery life cycle
  • Periodic trend analysis of bearing currents, rotor orbit, and air gap data for early fault detection

Field experience from gas compression installations reported by Baker Hughes and Siemens Energy indicates that magnetic bearing compressors in pipeline service achieve over 99.5% availability with scheduled maintenance intervals of 3–5 years, compared to oil-lubricated machines that typically require annual lube oil system service and more frequent inspections. The data represents installations with thousands of operating hours accumulated in North American and European pipeline networks.

Magnetic Bearing Cost Analysis: Initial Investment vs Lifecycle Value

The upfront cost of an active magnetic bearing system is higher than that of a conventional rolling-element or fluid-film bearing system. This fact is well established and must be addressed directly in any procurement evaluation. However, upfront cost alone is an incomplete picture.

Indicative lifecycle cost elements for a 5 MW centrifugal compressor over 20-year operating life. Figures are representative estimates based on published OEM service data and industry experience; actual values vary significantly by site conditions and contract structure.
Cost Element Oil-Lubricated Fluid-Film Bearing Active Magnetic Bearing
Capital cost premium (bearing system only) Baseline +$200k–$400k
Lube oil skid and auxiliaries (capital) $150k–$300k $0
Annual lube oil and filter cost $20k–$50k/year $0
Bearing inspection and replacement (20 yr) $300k–$600k $80k–$150k (touchdown bearings only)
Unplanned downtime (20 yr estimate) Higher (bearing wear, oil contamination events) Lower (no contact wear failure mode)
Efficiency improvement (reduced friction) Baseline 0.5–2% power reduction at full load

When the capital cost savings from eliminating the lube oil system are offset against the AMB system premium, the net additional capital cost on a large compressor can be $50k–$200k rather than $200k–$400k. Over a 20-year operating life with average oil costs, the cumulative savings in consumables and planned maintenance alone can exceed the initial capital premium, before accounting for reduced unplanned downtime.

Frequently Asked Questions About Magnetic Bearings

What happens to a magnetic bearing if power is lost?

When power is lost to an active magnetic bearing, the rotor drops onto the auxiliary (touchdown) bearings. These are rolling-element bearings with a small clearance relative to the magnetic bearing gap. They are designed to safely support the rotor at full speed and allow it to spin down without contact with the electromagnet poles. The drop event is controlled and the machine comes to rest on the touchdown bearings. Every AMB system is required to include touchdown bearings, and every installation should include an uninterruptible power supply (UPS) to provide power for an orderly controlled rundown sequence rather than an immediate drop, which minimizes wear on the touchdown bearings.

Can a magnetic bearing support the same loads as a conventional rolling-element bearing of equivalent size?

In general, no. Magnetic bearings have a lower load capacity per unit of bearing diameter than rolling-element or fluid-film bearings. A rolling-element bearing of 100 mm bore might support a static load of several hundred kN; a magnetic bearing of similar outer diameter supports perhaps 10–30 kN depending on the electromagnet design and allowable power dissipation. This is why magnetic bearings are rarely used in applications requiring high radial loads at moderate speeds — their advantage is in high speed, precision, contamination sensitivity, or maintenance-free operation, not raw load capacity. Rotors for magnetic bearing systems must be designed with this load limitation in mind from the outset.

How long does an active magnetic bearing last?

The magnetic bearing stator and rotor components — the laminations, coils, and housings — are not wear parts and do not have a defined fatigue life in normal operation, because there is no contact between them. The limiting wear components are the touchdown bearings, which are replaced on a preventive schedule, typically every 3–5 years or after a specified number of rotor drop events. The electronics (power amplifiers, controller boards) have expected service lives of 10–15 years, with component-level repair or board replacement as needed. Field reports from pipeline and process compressor installations indicate that magnetic bearing machinery has operated for over 20 years with the original bearing hardware in service, with only touchdown bearing and electronics maintenance.

Is a magnetic bearing suitable for use in explosive atmospheres (ATEX/IECEx zones)?

Yes, magnetic bearing systems can be and are used in ATEX/IECEx classified hazardous areas. The electromagnets and sensors inside the bearing housing are in contact with the process gas, and these components can be designed and assessed for use in flammable gas environments. The control cabinet and power amplifiers are typically located outside the hazardous area in a safe room, connected to the bearing by screened cables. This separation of the active electronics from the hazardous area is standard practice in natural gas compression installations. Users should verify that the specific product configuration has the appropriate hazardous area assessment for their zone and gas group.

What is the difference between a magnetic bearing and magnetic levitation (maglev)?

Both use controlled magnetic forces to levitate an object without contact, but the applications and scales are different. Maglev transportation systems levitate and propel an entire train vehicle along a guideway, requiring large-scale linear electromagnetic infrastructure. Magnetic bearings support rotating shafts in machines — compressors, turbines, spindles, flywheels — and are a component within a larger machine rather than a transportation system in their own right. The underlying physics and control principles are closely related; in fact, active magnetic bearing research contributed directly to the control methods used in modern commercial maglev rail systems such as the Shanghai Transrapid line and the Japanese SCMaglev. At the functional level, a magnetic bearing is essentially a maglev system applied to a rotating axis within a machine housing.

Can magnetic bearings be retrofitted into existing rotating machinery?

Retrofit is technically possible but requires significant engineering work. The rotor must be modified or replaced to add the bearing landing journals with appropriate material and geometry, and the bearing housing must be redesigned to accommodate the electromagnet stators, sensors, and auxiliary bearings. The rotor dynamics will change with the new bearing stiffness and damping characteristics, so a full rotordynamic analysis and re-assessment of critical speeds is required. In some cases, the existing rotor design is compatible with magnetic bearing retrofitting; in others, a new rotor is needed. Several companies — including Waukesha Bearings and SKF Magnetic Mechatronics — have performed retrofit projects on centrifugal compressors, and published case studies are available from the Turbomachinery and Pump Symposia proceedings (Texas A&M University).

How does temperature affect magnetic bearing performance?

Temperature affects several components of a magnetic bearing system in different ways. The remanent flux density of permanent magnets decreases with increasing temperature — this is a primary design constraint for hybrid bearings using rare-earth permanent magnets, which can lose significant force capacity at temperatures above 150°C. The winding insulation in the electromagnet coils sets an upper temperature limit for the bearing stator; high-temperature class H or class N insulation extends this to 180°C or 200°C respectively. The ferromagnetic lamination material loses permeability as it approaches its Curie temperature (around 770°C for iron), reducing bearing force at very high temperatures. At the low end, cryogenic operation at liquid nitrogen or liquid helium temperatures is feasible — turbo-expanders in air separation plants and LNG facilities operate with magnetic bearings at cryogenic process gas temperatures.

Which industries are currently the largest users of magnetic bearing technology?

By installed base volume, the oil and gas / natural gas compression sector is the largest industrial user of active magnetic bearings in large turbomachinery. Vacuum equipment for semiconductor manufacturing is the largest user by unit count. Building HVAC is a growing segment driven by the adoption of magnetic bearing chillers by major brands. Medical device — specifically implantable cardiac assist devices — is a small but high-value market where the technology has become the clinical standard of care for advanced heart failure support. Energy storage via flywheels is an emerging segment with growing installations in grid frequency regulation.
